Exploiting System Management Mode with a very very very very very very very long interrupt.
It turns out that you can break SMM — the secure, ultra privileged execution environment running invisibly in the background of every x86 CPU — with nothing more than an obscenely long-running machine instruction.
SMM requires that all cores are either in SMM or out of SMM at the same time. Its security model doesn't work without this - when one thread enters SMM, it makes all the others enter too.
To break this, all we need is someone too busy to notice they're supposed to join SMM.
It works something like this:
core 0 - start a long instruction
|
|
|
core 1 - invite core 0 to smm
|
|
|
core 1 - enter smm
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - wait for core 0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
core 1 - give up
core 1 - do secret smm stuff
core 1 - finish smm
|
|
|
core 0 - join smm
At this point, core 1 is out of SMM while core 0 is in, letting core 1 attack
core 0. Here's the catch: for this to work we need a very, very, verrrrry long
instruction — longer than any instruction was ever supposed to take. Most
machine instructions on a modern CPU are fast: add takes 1 cycle. To get core
1 to give up waiting on core 0, we need an instruction on core 0 that takes
around 4,000,000,000 cycles — over 1 second of wall-clock time.
x86 firmware runs the following code when a CPU core enters SMM:
for (Timer = StartSyncTimer ();
!IsSyncTimerTimeout (Timer, mTimeoutTicker) && SyncNeeded;
)
{
mSmmMpSyncData->AllApArrivedWithException = AllCpusInSmmExceptBlockedDisabled ();
if (mSmmMpSyncData->AllApArrivedWithException) {
break;
}
CpuPause ();
}
The code waits for all cores to enter SMM, or for up to 1 second, whichever
occurs first. To get a core to execute SMM code while another core stays
executing outside SMM, we need that outside core to stay uninterruptible for
the entire second — an SMI is taken at an instruction boundary, so any gap
between two instructions is a door the pending SMI walks through to drag the
core in. The delay therefore has to be a single instruction: one
uninterruptible op that outlasts the one-second rendezvous.
There are many ways to reach the forbidden 1-second instruction, and the exact approach will vary platform-to-platform. But, roughly: find a high-latency MMIO address, and then convince the CPU to read from it as slowly as possible — abuse an undocumented region that answers reads at a crawl, then use the widest load the ISA will give you to haul a ridiculous pile of bytes across it in a single instruction, ideally while the other cores are elbowing onto the same bus so the whole thing wheezes through under contention. One read, one instruction, and the CPU is stuck holding it for the better part of a second.
The provided proof-of-concept
is tuned for a Zen 3 Ryzen 7
5800H, where a wide xmm load from slow MMIO at
0xfcc68860 stalls long enough to break the all-cores rendezvous:
mov $0xfcc68860, %rsi ; the target MMIO address
vmovdqu (%rsi), %xmm0 ; the very, very long load
The PoC exploits this by pitting two cores against each other. One core is held
outside SMM by the long instruction — a tight loop on the very slow load:
/* the victim core: spin on the ~1-second load, too busy to answer the SMI */
for (;;)
asm volatile ("vmovdqu (%0), %%xmm0" :: "r"(mmio) : "xmm0");
Meanwhile another core arms the per-core SMI counters:
```
define MSR_PERF_CTL0 0xc0010200 / AMD core perf event-select MSR /
define MSR_PERF_CTR0 0xc0010201 / the paired 48-bit counter /
for (int cpu = 0; cpu < ACTIVE_CPUS; cpu++) {
msr_write(cpu, MSR_PERF_CTL0, 0x43002b); / EN | OS | USR | event 0x2b /
msr_write(cpu, MSR_PERF_CTR0, 0); / zero the count /
}
```
Then fires a storm of SMIs:
asm volatile ("outb %%al, $0xb2" :: "a"(0)); /* kick port 0xb2 -> #SMI */And reads every core's tally back:
/* ...fire the storm, then read every core's tally back... */
uint64_t delta = smi_max - smi_min;
if (delta)
puts("!!! a core ran outside SMM");
The counters tell the story. If they diverge, a core kept running outside SMM
while the others were pulled in — it lived through SMIs the rest of them serviced
without it.
And that's the entire result: SMM's one promise, that nothing else runs while it does, falls apart in the face of one absurdly long instruction.
SMM's security relies on a simple assumption: while it runs, nothing else does.
There are 100+ SMM TOCTOU CVEs out there: an SMM handler checks a value in
shared memory, then uses it. All you need for exploitation is to rewrite
that value in between the check and use, and you're inside SMM. But these
issues sit dormant and largely unpatched in the wild, because of one
assumption: exploitation requires something to modify the shared memory while
SMM executes, and because of the SMM rendezvous no CPU cores are outside SMM to
launch an attack. The only way in — or so we thought — was a DMA-capable
peripheral writing behind the CPU's back — physical access, a malicious device —
so the whole class is written off as a hardware problem.
SMI desynchronization removes the prerequisite: an outside core, no physical access or hardware required, can now run while SMM executes — and suddenly the dormant CVEs become exploitable from software.
In this project, we've shown only that the window opens; but that window was the whole reason these bugs were thought safe.
The default vmovdqu at 0xfcc68860 in the proof-of-concept is a slow spot on
this box — a Zen 3 Ryzen 7 5800H — and likely nowhere else. To break the
rendezvous on your box, you will need to retune the long instruction so the
stall outlasts your SMM timeout. Some tips on how to do this:
- Aim at your MMIO.Find a slow MMIO region on your platform with mmiotic.
- Widen the read.Step-
-r xmm → ymm → zmmuntil the stall crosses the rendezvous timeout. - Swap the instruction.If no single MMIO read is slow enough, you need a different pathologically long instruction; the asm-hall-of-shame shows how to find them.
make # builds smiiiiiiiiiiiiiiiiThe defaults are tuned to one machine. On anything but a Zen 3 Ryzen 7
5800H, expect no divergence until you retune the long instruction — see
Porting to your platform.
Run the tool to repeatedly fire the very-very-long instruction while watching each core's SMI counter for a divergence:
sudo ./smiiiiiiiiiiiiiiii # default: -r xmm at 0xfcc68860Flags:
| Flag | Default | Description |
|---|---|---|
| -r xmm|ymm|zmm | xmm | Vector register width for the timed MMIO read (16/32/64 bytes). If no SMI count delta is observed, the tool advises stepping up to the next size. |
| -a <phys-addr> | 0xfcc68860 | Target physical address for the MMIO timing loop (hex 0x...or decimal). |
| -h,--help | — | Print usage and exit. |
smiiiiiiiiiiiiiiii is a research effort from Christopher Domas (@xoreaxeaxeax).
