Passphrase-less reboots using kexec under NixOS
Encrypted hard drives protect data, including in the event of theft. Even if entire racks are carried out of the server room: without the correct passphrase for disk encryption, the hard drives are of little use. So of course we encrypt them. So far, so obvious.
This security, however, comes at a price. Every instance of human intervention during a reboot costs time and increases the risk of errors: if the boot process is interrupted, whether due to distraction or any imaginable incident, the server gets stuck at the password prompt and fails to boot up again.
We sometimes find ourselves needing to reboot servers more frequently. While a lot of software can be updated or reconfigured on the fly, this option stops at the Linux kernel: eventually, a reboot is required. Thatâs why we wanted a solution that allows us to reboot servers without the need for a manual decryption step.
Of course, one could try to automate our existing process, letting another computer with access to the passphrase connect to the rebooting server via SSH and decrypt it. However, this type of automation is tricky, because it turns the whole thing into a distributed system, with all the problems that entails. We wanted a solution in NixOS that does not depend on another computer, but retains the security of our existing solution. And thatâs what we have achieved using kexec.
Faster reboots with kexec
The kexec mechanism lets the kernel (k) execute another kernel (exec). Which means: The running kernel replaces itself with a new one without the actual server (i.e. the hardware) being shut down and restarted. Only the operating system restarts. The clever part: the old kernel can make information available in RAM that the new kernel can use. A passphrase for decrypting the hard drive, for example. As a nice side effect, we skip the firmware and bootloader parts of the reboot, saving several minutes of rebooting time, particularly on servers.
Securely passing passphrases
The LUKS passphrase could also be passed by simply writing it into a file before the reboot. But thereâs a catch: During a full reboot, the system shuts down completely. For the newly starting kernel to be able to read this file, it would have to be stored unencrypted, which would undermine the security of our hard drive encryption. With kexec, the data can be passed via the serverâs volatile RAM. This is a bit tricky though. In this article, weâll show you how we implemented it.
Security and convenience â both is possible
You canât have your cake and eat it, too? We simply didnât want to accept this supposed wisdom for the matter of rebooting our servers. We want all of it: the security of full-disk encryption, of course, but also convenience, speed and reliable reboots. And if thereâs one thing we donât do, itâs giving up quickly just because something doesnât work straight away.
So we set out to find a solution and came across two interesting sources with different approaches:
- A comment in a lobste.rs thread.
- The blog article Encrypted NixOS home server with passwordless reboot.
Both approaches have their pros and cons; neither was quite enough for us. Thatâs why we took the best bits from both and built our own solution.
Approach No. 1: One-time passphrases
We generate a temporarily valid passphrase. But we donât stop there. Because you can manage multiple keyslots in LUKS. So we also create a keyslot, assign this temporary passphrase to it, and delete the keyslot immediately after a successful kexec. This ensures our encryption remains secure even if the temporary passphrase were to be leaked for any reason.
Approach No. 2: Do not pass the passphrase on the command line
Even though the passphrase is invalidated immediately on the next boot, we want to take extra care to ensure that nobody can read it from the kernel command line, not even in the brief moment it takes us to invalidate the one-time passphrase. We therefore use the technique described in the blog post mentioned above: the one-time passphrase is embedded in a special initramdisk image, which is created specifically just before the kexec reboot.
Our solution for passphrase-less reboots
And this is our specific solution: We extend systemd.services."prepare-kexec" with the following steps:
- We create a temporary LUKS passphrase in an additional key slot.
- We create a new initrd image and add a file containing the key (in RAM).
- We configure the use of this key file via the kernel command line and enable a fallback to manual passphrase entry.
Immediately after mounting the root filesystem, we remove the key slot via a custom systemd unit defined in boot.initrd.systemd.services.
Our uninterrupted 2-minute reboot today
Today, our reboot no longer requires any manual intervention. And it now takes just over 2 minutes. A simple systemctl start kexec.target is all thatâs needed. Whether triggered manually or automatically, the server comes back up fully functional and ready for use.
Passphrase-less reboots on NixOS to go
Would you like our complete implementation as ready-to-use code? You can find our code in a sample configuration below this article. Enjoy!
Sample NixOS module:
{ config, lib, pkgs, ...}:
let
luksDevice = config.boot.initrd.luks.devices."yourdevice".device;
in
{
# Concept:
# To reboot a server using kexec, we need to alter the nixos
# prepare-kexec script, because we use full disk encryption.
# We add a temporary, random key to LUKS keyslot 31. This key is
# also added to the init ram disk image.
# We have to set the keyfile and fallbackToPassword option in the
# luks.device."yourdevice".If the keyfile exists it will be used to
# decrypt the disk, if not it will ask for the passphrase.
# We immediately delete the LUKS slot after mounting.
systemd.services."prepare-kexec" = {
path = with pkgs; [ cpio cryptsetup gzip ];
script = lib.mkForce ''
set -euo pipefail
umask 0077
# Don't load the current system profile if we already have a
# kernel loaded.
if [[ 1 = "$(</sys/kernel/kexec_loaded)" ]] ; then
echo "kexec kernel has already been loaded, prepare-kexec skipped"
exit 0
fi
p=$(readlink -f /nix/var/nix/profiles/system)
if ! [[ -d $p ]]; then
echo "Could not find system profile for prepare-kexec"
exit 1
fi
if ! [[ -f "/LUKS-Passphrase-file.txt" ]]; then
echo "Could not find luks-passphrase file"
exit 1
fi
# add 256 random bytes temp key to the LUKS keyslot 31
TEMP_DIR="$(mktemp -d --tmpdir=/dev/shm)"
mkdir "$TEMP_DIR/etc"
head -c 256 /dev/urandom>"$TEMP_DIR/etc/tmp-passphrase"
cryptsetup luksAddKey --batch-mode --key-slot 31 ${luksDevice} "$TEMP_DIR/etc/tmp-passphrase"</LUKS-Passphrase-file.txt
# create a new cpio archive and append it to the original initrd
cd "$TEMP_DIR"
cp "$p/initrd" "$TEMP_DIR/initrd.img"
find etc | cpio -H newc -o | gzip >> "$TEMP_DIR/initrd.img"
# load the kernel with the new initrd
kexec --load "$p/kernel" --initrd="$TEMP_DIR/initrd.img" --append="$(cat "$p/kernel-params") init=$p/init"
'';
};
boot = {
initrd = {
luks.devices."yourdevice" = {
fallbackToPassword = true;
keyFile = "/etc/tmp-passphrase";
};
systemd.services.clear-luks-keyslot = {
description = "Clear the LUKS key slot after successful kexec";
wantedBy = [ "initrd.target" ];
after = [ "systemd-cryptsetup@root.service" ];
serviceConfig.Type = "oneshot";
path = with pkgs; [ cryptsetup ];
script = "cryptsetup luksKillSlot --batch-mode ${luksDevice} 31 || true";
postMountCommands = ''
${pkgs.cryptsetup}/bin/cryptsetup luksKillSlot --batch-mode ${luksDevice} 31 || true
'';
};
};
}
