This project provides a lightweight, self-hosted CCTV solution designed for Linux-based single-board computers (SBCs) and standard USB webcams. It offers an affordable, privacy-focused alternative for home monitoring by keeping your video data entirely under your control. Project Philosophy

  • Privacy-First: By storing all footage locally, this system eliminates the need for third-party cloud subscriptions and ensures your data never leaves your network.
  • Cost-Effective: Leverage existing hardware—such as a spare Linux board and a USB webcam—to build a fully functional surveillance system without recurring fees.
  • Minimalist Architecture: The software is optimized to run efficiently on low-power devices, ensuring high performance even on entry-level hardware.

Key Features

  • Hardware Agnostic: Highly compatible with a wide range of standard USB webcams.
  • Resource Efficient: Optimized specifically for Linux-based boards (e.g., Raspberry Pi, Orange Pi, or similar SBCs).
  • Data Sovereignty: Full control over your storage path, retention policies, and access methods.

  • Simple Deployment: Designed for quick setup and easy maintenance.

  • Live MJPEG streamwith a web dashboard

  • Motion detectionwith frame differencing
  • Automatic recordingwith a pre-motion buffer
  • Email alertswith a snapshot picture when motion starts
  • Telegram integration:- Automatic video upload after motion is recorded

  • Bot commands: /snapshot,/video <seconds>,/help

  • Night modelow-light enhancement (software CLAHE + brightness/contrast boost)

  • Recordings bulk actions: select all, send to Telegram, download ZIP, delete
  • Storage cleanupby age, total size, and emergency low-disk cleanup
  • systemd autostartready

  • Licensed under GNU AGPLv3

  • Python 3.10 or newer

  • OpenCV with V4L2 support (see installation options below)
  • A USB webcam (/dev/video0by default)
  • Optional: a Telegram bot token for Telegram notifications

  • Optional: SMTP credentials for email alerts

  • Verify OpenCV is available: python3 -c "import cv2; print(cv2.__version__)"If OpenCV is not installed, you have two options: - Option A — use a system OpenCV package(recommended on ARM boards such as the Odroid XU4, where a pre-built system package is usually optimized for the board).

  • Option B — install OpenCV via pip(convenient on x86/amd64 machines or when no system package is available). Use- opencv-python-headlessbecause the app does not need a GUI.

  • Create and activate the virtual environment and install the app: This creates a venv that can see the system site-packages, so the system cv2is available inside the venv.cd $HOME/CheapSecurity python3 -m venv venv --system-site-packages source venv/bin/activate pip install -e . Use this if you do not have a system OpenCV or prefer a self-contained venv. cd $HOME/CheapSecurity python3 -m venv venv source venv/bin/activate pip install opencv-python-headless pip install -e . Note:On some older ARM boards the pipopencv-python-headlesswheel may not be available or may be slow. If that happens, install OpenCV from your distribution’s package manager instead and use Option A.

  • Find your webcam device (usually /dev/video0):v4l2-ctl --list-devices
  • Copy config.json.exampletoconfig.jsonand edit it:cp config.json.example config.json nano config.json - Set camera device, resolution, and frame rate
  • Fill in SMTP credentials if you want email alerts
  • Fill in Telegram bot token and chat ID if you want Telegram uploads
    Security:config.jsonis listed in.gitignoreand must never be committed. It contains passwords and tokens. Always editconfig.json, notconfig.json.example. If you add a new setting, update both files so the example stays in sync.
  • Run the app: ./venv/bin/python -m cheapsecurity.app
  • Open the dashboard in a browser: http://<odroid-ip>:5000

Edit config.json:

| Section | Key | Description |
|---|---|---|
| camera | device | V4L2 device index ( 0=/dev/video0) |
| camera | width,height,fps | Capture resolution and frame rate |
| camera | night_mode | Enable low-light enhancement |
| camera | night_mode_fps | Target FPS in night mode (camera may ignore this) |
| camera | night_mode_gain | Target analog gain in night mode (camera may ignore this) |
| camera | night_mode_brightness | Brightness boost in night mode |
| camera | night_mode_contrast | Contrast boost in night mode |
| motion | threshold | Pixel difference threshold (0-255) |
| motion | min_area | Minimum contour area to trigger motion (full-res pixels) |
| motion | cooldown_seconds | Keep recording after motion stops |
| motion | scale | Downscale factor for motion detection (saves CPU) |
| recording | dir | Where videos are saved |
| recording | max_duration_seconds | Maximum length of one clip |
| recording | pre_buffer_seconds | Seconds before motion included in clip |
| recording | codec | Preferred FourCC codec ( MJPGfor low CPU,mp4vfor smaller files) |
| notifications | enabled | Send email alerts on motion |
| notifications | smtp | SMTP server, port, username, password, TLS |
| notifications | from,to,subject | Email sender/recipients/subject (use ["a@...", "b@..."]for multiple recipients) |
| notifications | min_interval_minutes | Minimum time between alert emails |
| telegram | enabled | Send videos to Telegram after motion is recorded |
| telegram | bot_token,chat_id | Telegram Bot API token and destination chat |
| telegram | send_video | Whether to upload the video file automatically |
| telegram | min_interval_minutes | Minimum time between Telegram uploads |
| telegram | poll_commands | Enable /snapshot,/video, and/helpbot commands |
| storage | max_age_days | Delete recordings older than this (default 3 days = 72h) |
| storage | max_size_gb | Delete oldest files if total exceeds this |
| storage | cleanup_interval_minutes | How often storage cleanup runs |
| storage | delete_old_on_startup | If false, old recordings are kept when the app restarts |
| storage | emergency_free_space_gb | If free disk space drops below this, delete old recordings before a new one |
| storage | emergency_delete_count | How many oldest recordings to delete in an emergency cleanup |
| web | host,port | Dashboard bind address and port |
| web | stream_scale | Downscale factor for live stream (saves bandwidth/CPU) |
| web.auth | enabled,username,password | Optional HTTP Basic Auth |

  • Open Telegram and message @BotFather.
  • Send /newbotand follow the prompts to choose a display name and username.
  • Copy the bot token(looks like123456789:ABCdefGHIjklMNOpqrsTUVwxyz).

  • Keep this token secret — anyone with it can control your bot.

  • Start a private chat with your new bot and send any message (for example, /start).

  • Open this URL in a browser, replacing <YOUR_BOT_TOKEN>with the real token:https://api.telegram.org/bot<YOUR_BOT_TOKEN>/getUpdates
  • Look for "chat":{"id":123456789. The number is yourchat ID.- If getUpdatesis empty, send another message to the bot and refresh.

  • If you want to use a group chat, add the bot to the group first and send a message there; the chat ID will be negative for groups.

  • If

  • Copy the chat ID exactly, including the -sign if it is a group.

Fill in the telegram section of config.json:

"telegram": { "enabled": true, "bot_token": "123456789:ABCdefGHIjklMNOpqrsTUVwxyz", "chat_id": "123456789", "send_video": true, "min_interval_minutes": 5, "poll_commands": true }
Then restart the service:

sudo systemctl restart cheapsecurity@$(whoami).serviceAfter a motion clip is saved, the video is uploaded to your Telegram chat. Uploads are rate-limited by min_interval_minutes.

From your configured chat, send:

  • /snapshot— receive the current camera picture
  • /video 10— record and send a 10-second video (1–60 seconds, default 10)
  • /help— list commands

The bot only responds to your configured chat_id.

Motion has priority: if the system is already recording because motion was detected, a /video request will not interrupt it. The bot will reply that a motion video is in progress and will be uploaded automatically.

Configure the notifications section in config.json. A picture from the moment motion starts is attached. Alerts are rate-limited by min_interval_minutes.

Google no longer allows "less secure apps" to use your regular Gmail password. You must create an App Password.

  • Enable 2-Step Verificationon your Google account:
  • Create an App Password:
  • Go to https://myaccount.google.com/apppasswords
  • Select app: Mail
  • Select device: Other (Custom name)— type "CheapSecurity"

  • Click Generateand copy the 16-character password (for example,abcd efgh ijkl mnop).

  • In config.json, set:"notifications": { "enabled": true, "smtp": { "server": "smtp.gmail.com", "port": 465, "username": "you@gmail.com", "password": "abcdefghijklmnop", "use_tls": true }, "from": "you@gmail.com", "to": "you@gmail.com", "subject": "CheapSecurity motion alert", "min_interval_minutes": 5 } - Use the App Password(no spaces) in thepasswordfield, not your Google account password.

  • For Google Workspace accounts, the username is usually your full email address.

  • The app uses implicit TLS (SMTP_SSL) on the port you configure. Gmail accepts this on port 465.

  • Use the

"to": [ "you@gmail.com", "family@example.com" ]
Night mode combines:

  • Software enhancement(CLAHE on the L channel)
  • Camera brightness/contrast boost
  • Attempts to lower FPS and raise gain/ISO if the camera supports it

Toggle it from the dashboard. It is applied to the live stream, recordings, and alert pictures.

Important: most USB webcams do not expose ISO/gain/exposure controls via V4L2, so FPS/gain adjustments may be ignored. True night vision requires an IR-sensitive camera and an IR illuminator.

  • Recordings are saved in recordings/.
  • Recordings older than max_age_daysare deleted during periodic cleanup,noton startup (unlessdelete_old_on_startupistrue).
  • If free disk space drops below emergency_free_space_gb, the oldestemergency_delete_countrecordings are deleted before starting a new clip.

  • Recordings older than max_age_daysor exceedingmax_size_gbare removed during periodic cleanup.

  • Live stream

  • Status panel (resolution, FPS, recording state, motion state)
  • Settings toggles: night mode, email notifications, Telegram uploads, built-in basic auth
  • Recordings list with per-row checkboxes and bulk actions:
  • Select all
  • Send to Telegram
  • Download selected(ZIP)
  • Delete selected

Do not expose Flask's development server to the internet. Use Gunicorn behind the built-in auth or another reverse proxy you trust.

It is already defined in pyproject.toml:

cd $HOME/CheapSecurity source venv/bin/activate pip install -e .
Copy the service template and enable it from a user shell:

sudo cp cheapsecurity.service /etc/systemd/system/cheapsecurity@.service sudo systemctl daemon-reload sudo systemctl enable --now cheapsecurity@$(whoami).service
This binds Gunicorn to 0.0.0.0:5000 with one worker and four threads, so the dashboard and stream are reachable directly on your network. Only one worker is used because the camera must be opened by a single process.

Security:if you expose this to the internet, put a reverse proxy with HTTPS and authentication in front of Gunicorn. If you only access it locally, keep the built-in auth enabled.

View logs:

`sudo journalctl -u cheapsecurity@$(whoami).service -f` CheapSecurity/ ├── src/ │ └── cheapsecurity/ # Python package │ ├── app.py # Development launcher │ ├── cctv.py # Motion detection, recording, alerts, Telegram bot │ ├── web.py # Flask dashboard and APIs │ ├── wsgi.py # Production WSGI entry point │ ├── diagnose.py # Diagnostic/troubleshooting script │ ├── templates/ # HTML templates │ └── static/ # CSS/JS ├── tests/ # Test suite ├── config.json # Your local settings (gitignored, never commit) ├── config.json.example # Example settings template (committed) ├── pyproject.toml # Package metadata and dependencies ├── cheapsecurity.service # systemd template ├── LICENSE # GNU AGPLv3 └── recordings/ # Saved videos
If recordings stop appearing:

  • Check the service is running:
    sudo systemctl status cheapsecurity@$(whoami).service
  • Check logs:
    sudo journalctl -u cheapsecurity@$(whoami).service -f
  • Run the diagnostic script:
    source venv/bin/activate python -m cheapsecurity.diagnose
  • Try lowering motion.min_areaif no motion is detected.

This project is licensed under the GNU Affero General Public License v3.0 or later (AGPLv3). See LICENSE.
