This is a proposal, not the final specification. Details, terminology, and behaviors are all likely to change.

For discussion, head to the community forum.

For a friendlier introduction to the problem space and deeper analysis of design decisions made along the way, see the permissioned data diary blog posts.

Current drafts of lexicons can be viewed on the implementation branch in the atproto repo. Note that the implementation itself is still very much a work in progress.

AT Protocol (atproto) is a foundation for building social applications on shared, user-owned data. While commonly referred to as a "protocol", atproto is actually a framework composed of several distinct protocols as well as a schema language. Atproto currently includes a data repository and sync protocol for public broadcast data.

In the public broadcast protocol, users publish records into a repository on their PDS, and applications crawl those repositories to build views. Records are signed, redistributable, and universally addressable, with authority resting in the DID that publishes a record.

This document specifies an additional data protocol for permissioned data, or data with an access perimeter. The permissioned data protocol serves modalities such as:

  • Personal data: bookmarks, mutes, drafts
  • Gated content: paid newsletters, subscriber-only posts
  • Socially shared: private posts, stories
  • Groups: private forums, communities, group chats

The permissioned data protocol shares the abstract shape of public broadcast. It retains DID-based authority, per-user repositories, lexicon-typed records, and the general flow of applications crawling PDSes to build views. However it has its own repository format, sync mechanism, addressing scheme, and resolution path. Public broadcast is built for open distribution (signed, archival, rebroadcastable) while the permissioned data protocol is built for party-to-party transmission within an access boundary.

The permissioned data protocol provides access control, not confidentiality. It is not end-to-end encrypted. Services (both PDSes and authorized applications) can read the data they handle, which is required for server-side features such as search, indexing, notifications, aggregation, and moderation. E2EE is a separate concern that may be layered on top by an application and is out of scope in this proposal.

| Public broadcast | Permissioned data | |
|---|---|---|
| Unit of data | Record in a repo | Record in a permissioned repo |
| Repo scope | One repo per user | One permissioned repo per (user, space) |
| Record authority | User DID | User DID |
| URI authority | User DID | Space authority DID |
| Commit | Merkle Search Tree root | LtHash set-hash digest |
| Signature | Rebroadcastable, archival | Deniable on rebroadcast |
| Addressing | Traditional at://URI | at://URI withspacesegment |
| Access | Public | Gated by space credential |

  • Space: an authorization and sync boundary for a set of permissioned records, identified by an- (authority, type, skey)triple.
  • Permissioned repo: one user's records within one space, with a cryptographic commit, hosted on that user's PDS.
  • Repo host: a service that stores and serves users' permissioned repos.
  • Space host: a service that answers for a space as a whole, issuing credentials, enumerating writers, and routing notifications.
  • Space authority: the DID at the root of a space, which resolves to the space host and the key material for issuing credentials.
  • Space credential: a token issued by the space authority that grants read access to a space.
  • Delegation token: a token issued by a user's PDS that an application exchanges with a space authority for a space credential.
  • Client attestation: a token signed by an application's own client authentication key, proving the application's identity to a space authority. Required only when a space gates on client app identity.
  • Syncer: an application that keeps its own copy of a space in sync by pulling from repo hosts.

A PDS fulfills both the roles of a repo host and a space host. However, these roles are discussed separately because they do not necessarily need to be filled by a PDS. A permissioned repo or a space may be hosted by any service that implements the required APIs.

A space is an authorization and sync boundary representing a shared social context. A space may include many different types of records from many users. The space does not colocate records on a single network host. Instead, each user stores their own records for a given space in a permissioned repo on their own repo host. A space is the aggregation of these per-user repos across the network: an application presenting a space pulls each member's repo from its host, assembles the view, and applies access control to requesting users.

Each space is identified by three values:

  • space authority: a DID, the root of authority for the space
  • space type: an NSID describing the modality of the space
  • space key(- skey): a string distinguishing spaces of the same space type under the same space authority

Reading or syncing a space requires a space credential signed by the declared signing key of the space authority. The space authority decides whether to issue one based on the requesting user and client application. The protocol does not define how that decision is made and carries no member list (see Access Control). Spaces scale from a single user's personal data (e.g. bookmarks) to communities of millions of users.

A permissioned record is addressed by an at:// URI with a fixed space segment:

at://{spaceDid}/space/{spaceType}/{skey}/{authorDid}/{collection}/{rkey}
| Component | Type | Description |
|---|---|---|
| spaceDid | DID | Space authority DID |
| space | literal | Fixed marker identifying this as a permissioned space URI |
| spaceType | NSID | Space type |
| skey | string | Space key |
| authorDid | DID | DID of the record's author |
| collection | NSID | Record collection |
| rkey | string | Record key |

Permissioned data reuses the at:// scheme rather than defining its own. The literal space segment sits where a collection NSID appears in a public atproto URI, so a permissioned URI is distinguished from a public one by that marker in the first path segment under the authority DID. The two are never ambiguous, as a public collection is an NSID, which always contains at least two .s, whereas the space marker contains none.

All segments through rkey are necessary to identify a permissioned record. The leading segments through skey may be used to reference a space:

Space: at://{spaceDid}/space/{spaceType}/{skey} Record: at://{spaceDid}/space/{spaceType}/{skey}/{authorDid}/{collection}/{rkey}
A space's authority is the DID at the root of the space and the issuer of its credentials. It may be a user's own DID as for personal data such as bookmarks or mutes. Or it may be a dedicated DID which lets a shared space transfer between users independently of any individual account.

A space authority is resolved through two entries in its DID document:

  • a verification methodwith id#atproto_space: the public key used to verify the space's credentials
  • a serviceentry with id#atproto_space_host: the endpoint of the space host

Both entries are optional. When #atproto_space is absent, the space signing key falls back to the account's #atproto signing key. Similarly, when #atproto_space_host is absent, the space host falls back to the account's #atproto_pds service endpoint. An authority MAY instead publish the dedicated entries to point at distinct key material or a distinct host, and MAY set them to the same values as #atproto and #atproto_pds explicitly.

A space's type is an NSID that names its modality and resolves to a space type declaration. It identifies the kind of data a space holds before any network resolution, much as a collection NSID does in public atproto. Because a type names a concrete modality, every space is some specific kind of space rather than a generic container.

The type is also the OAuth consent boundary. Access is granted to a user by type, e.g. "access to your AtmoBoards forums" (see OAuth scopes).

A space type NSID resolves to a space type declaration: a Lexicon definition with "type": "space".

{ "lexicon": 1, "id": "com.atmoboards.forum", "defs": { "main": { "type": "space", "description": "A discussion forum", "key": "any", "name": "AtmoBoards Forum", "name:lang": { "es": "Foro AtmoBoards", "ja": "AtmoBoards 掲瀺板" }, "collections": ["com.atmoboards.thread", "com.atmoboards.reply"] } } }
| Field | Type | Required | Description |
|---|---|---|---|
| type | "space" | yes | Marks this as a space type declaration. Must be the maindefinition. |
| description | string | no | Description of the space type for developers. Not shown to users. |
| key | string | yes | Specifies the recommended space key type (similar to record key types) |
| name | string (1–64) | yes | Human-readable name for the space type, shown to users on consent screens. |
| name:lang | map | no | Localized namevalues by language code. |
| collections | array of NSID | yes | Collections clients should expect in a space of this type. |

The collections field is the default collection set for a space: scope of this type. However, ultimately any collection may be written to any space and is not constrained at the protocol level by the collections in a space type declaration.

The space key (skey) is a string distinguishing spaces of the same type under the same authority, analogous to a record key (rkey): a slug, a TID, a cryptographic identifier, or a reserved string such as self. Maximum length 512 bytes with the same syntax requirements as an rkey.

Reading a space is gated by a space credential issued by the space authority. The authority issues one based on two axes:

  • which useris being acted for: established by a- delegation tokenminted by the user's PDS
  • which applicationis acting: established by a- client attestationsigned by the application itself

The delegation token is always required. The client attestation is required only when a space gates on client app identity. An application obtains a credential by getting a delegation token from a user's PDS, then presenting that token (together with its client attestation, if needed) to the space authority in exchange for a credential. The authority decides whether to issue the credential. The protocol does not define the decision procedure (the policies of the PDS's space-management implementation are described under simplespace).

Some spaces do not require a client attestation. This can be detected by querying the space configuration, or by simply making a request for a credential without an attestation and seeing whether an error is returned.

A delegation token proves that an application is acting on a user's behalf when it asks an authority for a space credential. The user's PDS mints it, requested through com.atproto.space.getDelegationToken. It asserts only the delegation from user to application. Whether the user is a member of the space is the authority's determination, and the delegation token says nothing about it. The token is single-use, short-lived (default 60 seconds), and addressed (aud) to the space authority.

A client app session can only request a delegation token for a space it has been authorized to access. The application must hold a covering space: OAuth scope (specifically a read grant, which confers access to getDelegationToken).

A delegation token is structurally similar to an atproto service auth token, but it differs in a few ways that make it its own credential class rather than an interchangeable one:

  • The typfield in the header is set toatproto-space-delegation+jwt.
  • It does not include an lxmclaim.
  • It is bound to a target space through the subclaim.

Example JWT header and payload (before base64url encoding and signing):

{ "typ": "atproto-space-delegation+jwt", "alg": "ES256K", // or ES256 "kid": "#atproto" // Key Identifier - MUST be "#atproto" } { "iss": "did:example:user_did", // User DID "sub": "at://did:example:space_did/space/com.example.space_type/space_key", // Space being requested "aud": "did:example:space_did#atproto_space_host", // Space host (service fragment of the authority DID) "iat": 1738368000, // Issued-at (unix seconds) "exp": 1738368060, // iat + 60 (60 seconds) "jti": "f47ac10b58cc4372a5670e02b2c3d479" // random nonce }
The delegation token asserts only the user-to-app delegation; it says nothing about which application is acting. App identity is established independently by the client attestation, which the authority verifies itself. The two are presented together but signed by different parties and evaluated independently.

The signature for the delegation token is computed using the regular JWT process, using the account's signing key. For more details, see the Inter-Service Authentication section of the AT Protocol spec.

A client attestation is a short-lived, single-use JWT that the application presents to the space authority alongside the delegation token to identify itself, when the space requires it. It is structurally a private_key_jwt client assertion, the same shape an atproto confidential client already presents to its authorization server, but addressed to the space authority rather than to the PDS.

{ "typ": "atproto-client-attestation+jwt", "alg": "ES256", "kid": "key-1" // Key id from the client's published JWKS } { "iss": "https://app.example.com/client-metadata.json", // The client_id "sub": "https://app.example.com/client-metadata.json", // The client_id (== iss) "aud": "did:example:space_did#atproto_space_host", // Space host being asked for a credential "iat": 1738368000, // Issued-at (unix seconds) "exp": 1738368060, // short-lived "jti": "b3c4d5e6f7a8b9c0d1e2f3a4b5c6d7e8" // random nonce, replay protection }
The authority verifies the attestation by resolving iss (the client_id) to the client's client-metadata.json, fetching its published JWKS (jwks or jwks_uri), and verifying the signature against the key in that JWKS identified by the attestation's kid.

A space credential is the token an application presents to a repo host to read a permissioned repo within a space. The authority mints it in exchange for a delegation token, requested through com.atproto.space.getSpaceCredential. It is short-lived (default 2 hours) and signed by the space authority's signing key, so any repo host can verify it against the authority's key without contacting the authority.

A space credential is multi-use. A single credential is intended to be reused across every repo host serving a repo in the space as well as against a given host for repeated requests, until it expires.

A space credential resembles a space delegation token, differing in these ways:

  • The typfield in the header is set toatproto-space-credential+jwt.
  • It is signed by the space authority rather than the user.
  • It has no aud: it is presented to any repo host serving a repo in the space, not to a single recipient.

Example JWT header and payload (before base64url encoding and signing):

{ "typ": "atproto-space-credential+jwt", "alg": "ES256K", // or ES256 "kid": "#atproto_space" // Key Identifier - "#atproto_space" or "#atproto" } { "iss": "did:example:space_did", // Space authority DID "sub": "at://did:example:space_did/space/com.example.space_type/space_key", // Space the credential reads "iat": 1738368000, // Issued-at (unix seconds) "exp": 1738375200, // iat + 7200 (2 hours) "jti": "9f8e7d6c5b4a3210fedcba9876543210" // random nonce }
The signature for the space credential is computed using the regular JWT process, using the space authority's signing key.

β”Œβ”€β”€β”€β”€β”€β”€β” β”Œβ”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β” β”Œβ”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β” β”Œβ”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β” β”‚ User β”‚ β”‚ User's PDS β”‚ β”‚ Application β”‚ β”‚ Space Authority β”‚ β””β”€β”€β”€β”¬β”€β”€β”˜ β””β”€β”€β”€β”€β”€β”€β”¬β”€β”€β”€β”€β”€β”˜ β””β”€β”€β”€β”€β”€β”€β”¬β”€β”€β”€β”€β”€β”€β”˜ β””β”€β”€β”€β”€β”€β”€β”€β”€β”¬β”€β”€β”€β”€β”€β”€β”€β”€β”˜ β”‚ β”‚ β”‚ β”‚ β”œβ”€β”€ OAuth consent ───► β”‚ β”‚ β”‚ β”œβ”€β”€β”€β”€β”€ OAuth token ─────► β”‚ β”‚ β”‚ β”‚ β”‚ β”‚ ◄─ getDelegationToken ─── β”‚ β”‚ β”œβ”€β”€ delegation token ───► β”‚ β”‚ β”‚ β”‚ getSpaceCredential β”‚ β”‚ β”‚ β”œβ”€(token [+ attestation])─►│ β”‚ β”‚ ◄──── space credential ─────
- The user authorizes the application via OAuth.
- The application calls com.atproto.space.getDelegationTokenon the user's PDS, receiving a delegation token.
- The application presents the delegation token to the space authority via com.atproto.space.getSpaceCredential, adding its own client attestation if the space gates on client app identity. The authority verifies what it received and, on authorization, returns a space credential.
- The application reads the repo from each member's repo host with the credential.

An application serving several users of a space does not necessarily need to maintain a space credential for each user. It may obtain its credential using any one user's session. When it loses all OAuth sessions for a space, it can no longer renew the credential and loses access.

A permissioned repo is one account's set of records within one space, generally stored on that user's own PDS. A user has one permissioned repo per space it participates in. Abstractly, a permissioned repo offers a similar interface to a public atproto repository: a key/value mapping where keys are path names (a collection NSID and an rkey) and values are CBOR-encoded records. PDSes expose a CRUD interface for interacting with a user's permissioned repos.

Each permissioned repo is summarized by a commit. A commit is a short, signed digest that allows a syncer to check whether its copy of a repo matches the source without resyncing it in its entirety.

The digest in a commit is computed from a set hash over the records a repo currently contains. It is independent of write/delete order, so two repos with the same records always produce the same digest. Adding or removing a record is a single cheap operation, so a repo host maintains the set hash incrementally on each write.

The construction is LtHash, a homomorphic hash built on a lattice problem (and thus quantum-secure). A record is added to or removed from the digest with a single addition or subtraction rather than a recomputation over the whole repo.

The state is a fixed 2048-byte buffer, interpreted as 1024 little-endian unsigned 16-bit lanes.

Each record in the repo maps to one element, the UTF-8 bytes of {collection}/{rkey}/{record_cid}. As with the public repository, the components are currently limited to ASCII, so the encoding (though specified as UTF-8) is a no-op.

To add an element:

  • Expand the element to 2048 bytes with BLAKE3 in XOF (extendable-output) mode.
  • Read those bytes as 1024 little-endian uint16lanes.
  • Add each lane into the corresponding state lane, modulo 65536 (2^16, i.e. with wraparound)

To remove an element, perform the same process, but subtract its lanes instead (modulo 65536).

Both operations are commutative, so the state depends only on the current set of records, not the order of writes. The empty repo's state is all zeroes.

The commit's hash is sha256(state), a 32-byte digest of the 2048-byte buffer. The repo host maintains the full state. Only the hash is carried in a commit.

A user does not sign the digest directly since a signature over the content digest would be a rebroadcastable proof of what the user wrote in a private space. Instead the signature covers only random per-commit bytes, and the digest is bound to those bytes by a symmetric MAC. A reader in the sync flow gets full authenticity and integrity, but a leaked commit is deniable and proves nothing about its contents to a third party.

Both the signature and the MAC are domain-separated by a single context string, ctx, built once and reused for both. ctx uses the variable-length-vector encoding from TLS 1.3 (Β§3.4). It is composed of a fixed protocol tag followed by each variable field length-prefixed with a big-endian uint16.

Note: these length prefixes are big-endian, following the TLS convention for wire encodings. This is the opposite byte order from the little-endian lanes of the commit digest, which follows the LtHash reference construction. The two come from different specs and each keeps its native byte order.

ctx = "atproto-space-v1" // fixed protocol tag || uint16be(len(space)) || space // space URI (at://authority/space/type/skey) || uint16be(len(author)) || author // author DID of the repo || uint16be(len(rev)) || rev // commit revision (TID) || uint16be(len(ikm)) || ikm // per-signature nonce (below)
A commit is then produced as follows:

  • Generate ikm, 32 fresh random bytes. A newikmis generated for each reader the commit is served to.
  • Compute sig = sign(ctx)with the user's signing key. The signed message only contains the space, author DID, revision and ikm, not the current repository hash.
  • Compute mac = HMAC-SHA256(HKDF-SHA256(ikm, ctx), hash), binding the repository hash to this commit's context.

A reader verifies sig against the user's signing key (authenticity), then recomputes mac and compares (integrity). Because the digest is bound by a symmetric MAC keyed from the public ikm, anyone holding the commit can compute a valid mac for any hash, so a rebroadcast commit cannot prove what the user wrote, only that they signed a (space, author, rev, ikm) context.

The signed commit (com.atproto.space.defs#signedCommit):

| Field | Type | Description |
|---|---|---|
| ver | integer | commit format version, currently 1 |
| hash | bytes | sha256of the LtHash state (32 bytes) |
| ikm | bytes | per-signature nonce (32 random bytes) |
| sig | bytes | sign(ctx)by the user's signing key |
| mac | bytes | HMAC-SHA256(HKDF-SHA256(ikm, ctx), hash) |
| rev | string | commit revision (TID), also bound into ctx |

The ver field is fixed at 1 for this version of the protocol. It corresponds to the version carried in the ctx protocol tag (atproto-space-v1).

A permissioned repo may be serialized to a CAR file, the same serialization format used to export a public atproto repository. It is served by com.atproto.space.getRepo and is the transport for full-state recovery. Blobs are not included and are fetched separately via getBlob.

The CAR header declares two roots, in order:

  • the signed commitβ€” thesignedCommitblock described above
  • the indexβ€” a DRISL (DAG-CBOR) map from"{collection}/{rkey}"to the record's CID, with keys in lexicographic order

The record blocks follow the two roots, and MUST appear in the same lexicographic order as their index entries.

The serialization carries the information needed to reconstruct and verify the repo, and a consumer can validate it as a stream:

  • Verify the commit's signature and MAC. The commit's hashis now trusted.
  • Fold each index entry's {collection}/{rkey}/{record_cid}into a running set hash as it is read, then compare the result against the commit'shash. This authenticates the whole index without reading a single record.
  • Verify each record block against its own CID as it streams past.

Permissioned data sync is functionally similar to public atproto. Applications build views by pulling repos from their hosts. The major difference is that there is no relay to provide a collated firehose of data for the network as permissioned repositories are by their nature non-rebroadcastable. An application pulls directly from each repo host and is responsible for keeping its own copy in sync.

A syncer keeps its own copy of a repo and, alongside it, its own running set hash over that copy. This is the same digest that the repo host maintains. When the two digests agree, the syncer knows that their copy is exactly up-to-date with the hosted repo. If there is a disagreement, then the syncer knows their copy is behind or corrupted.

To advance, a syncer calls com.atproto.space.listRepoOps with a since revision. A repo host keeps an operation log of recent writes to each repo and returns the operations after since. Each entry is { rev (TID), collection, rkey, cid, prev }. The field cid is null for a delete and prev is null for a create. Multiple records may be mutated atomically, and this is captured by entries sharing a rev. The syncer applies each operation to its copy and updates its running set hash accordingly.

By default listRepoOps inlines each created or updated record's value alongside its operation, so a syncer advances in a single call without a getRecord round-trip per write. Only the current value for a path is inlined. If a record has been updated or deleted by a later operation, the host omits the intermediate (now stale) values. A syncer may set excludeValues to receive only the operation metadata (for example, to drive selective getRecord calls).

If a given oplog response includes the last available operation that occurred to a repo, then the response must also include the member's current signed commit. The syncer compares the commit's hash against its own running set hash. If they match, the syncer is fully in sync and the commit's signature authenticates that state. If they do not, the syncer has diverged and must fall back to a recovery process.

Sync is self-healing because its correctness rests on the set hash comparison rather than on receiving every operation. A missed operation is detected on a subsequent sync. A total disjunction in repository history is also recognizable, and is recovered from by syncing the repository contents in their entirety.

The oplog is a transport optimization rather than a committed data structure. Its contents and history are not guaranteed, and a repo host may compact or drop it, retaining only a backfill window. It is also reset on account migration, as a new repo host begins its oplog afresh and does not inherit the prior host's history. In any such case, a syncer that cannot find its since revision falls back to full-state recovery, which does not depend on the oplog.

In cases in which a syncer cannot proceed incrementally, it must recover by syncing the full state of the repository.

To do so, a syncer fetches the whole repo as a serialized CAR from com.atproto.space.getRepo. It folds the index into a running set hash and compares that against the signed commit to authenticate the index, then validates each record block against its index CID as it streams past, rebuilding its local copy. A syncer replacing an existing copy diffs the recovered structure against what it holds and keeps only the records it is missing.

For the narrower case of healing a copy that has only slightly diverged, a syncer may prefer to avoid transferring the whole repo. It can fetch the latest commit through com.atproto.space.getLatestCommit, enumerate the repo's structure (paths β†’ CIDs) with com.atproto.space.listRecords using excludeValues, diff that lightweight listing against its local copy, and fetch just the differing records with com.atproto.space.getRecord. This trades the single getRepo round-trip for a smaller total transfer when most of the repo is already held.

Blobs referenced by permissioned records are stored on the authoring repo's host and fetched via com.atproto.space.getBlob with the relevant space credential.

Write notifications inform syncers that a repo has advanced, so they can pull promptly instead of continuously polling for updates. A notification contains no record data, and states only that a given repo in a given space has reached a new revision.

A syncer subscribes to notifications by calling com.atproto.space.registerNotify. When called on a space host, this method subscribes to writes for all repos in a space. Generally, syncers should subscribe to the space host for all write notifications from the space. However, it can also be called on particular repo hosts to receive notifications for specific repos. registerNotify is authenticated with a space credential. The service that was registered against should return the expiration time for the registration which may be longer than the expiration window of the space credential.

When a member writes, their PDS sends a com.atproto.space.notifyWrite to each endpoint registered for that repo. A PDS may not otherwise know which services are syncing the space, which is why the space authority registers itself as a subscriber on each repo host. Members notify the authority, and the authority forwards each notification to the endpoints registered with it for the space. Each notified syncer then pulls the updated repo directly from the relevant repo host. The authority only routes notifications and does not carry record data.

A repo host does not need an explicit out-of-band registration step from the authority to know where to send these notifications. On the first write into a repo for a shared space (one whose authority is not the account's own DID), the repo host resolves the space authority's #atproto_space_host endpoint and auto-registers it as a subscriber for that repo. The authority may later un-register if it no longer wishes to be notified. (Personal-data spaces, where the authority is the account's own DID and the PDS plays both roles, need no such registration.)

Notifications are best-effort and are not required for eventual consistency. If a notification is dropped, the affected repo is caught up by a later write's notification, or by a periodic sweep by the syncer. A sweep may be done over the writer set. com.atproto.space.listRepos returns each repo's current rev, so a syncer can compare those revisions against the revisions it last pulled and re-sync only the repos that have advanced, rather than polling each repo individually.

Syncing an individual repo requires the syncer to know that the repo exists. To sync a space in full, or to begin syncing a space for the first time, an application requires the set of accounts whose repos hold data in the space. This writer set is retrieved from the space authority via com.atproto.space.listRepos.

Because it subscribes to updates from every repository in the space, the authority can easily maintain a complete and current record of which repos hold data in the space. Alongside each account, listRepos returns that repo's current rev and hash.

The writer set is a simple fetch and carries no commit or history. It enumerates accounts that have written at least one record into the space, not the broader set of accounts that are merely allowed to write (which the authority may not even track) nor those that may only read it. Accounts that may read the space are never enumerated at the protocol-level, though applications may choose to enumerate them through records published in the space.

The writer set is what the authority claims, and is not itself authoritative for any individual repo. It is current as far as the authority's notifications have kept it. A listed account's repo host is the source of truth for whether that repo actually holds data. A syncer treats the writer set as the starting point for discovery and confirms each repo by syncing it directly from its host.

A space may be deleted by its authority. The authority stops issuing credentials and no longer answers for the space. The authority also deletes its own repo in the space.

The authority then notifies registered syncers and known repo hosts of participating members with com.atproto.space.notifySpaceDeleted, over the same best-effort path as write notifications.

A syncer should delete every copy of the space's data it holds, both the repos it pulled and any derived state, as it is no longer authorized to retain them. A repo host should instead flag the member's repo as belonging to a deleted space rather than erase it. The data is the user's own, so the repo host decides how and whether to surface it to the user (e.g. an export, a grace period) before garbage-collecting.

A user grants an application access to spaces through a space: OAuth scope. The scope identifies a set of spaces by their (authority, spaceType, skey) identifier and states what the grant permits within them.

space:<spaceType>[?authority=<did>][&skey=<skey>][&collection=<nsid>...][&action=<action>...][&manage=<op>...]
| Parameter | Position | Multiple | Default | Values |
|---|---|---|---|---|
| spaceType | positional (required) | no | N/A | a space-type NSID, or *for any type |
| authority | query | no | self | a space authority DID, selffor the granting user's own DID, or*for any authority |
| skey | query | no | * | a space key (1–512 chars), or *for any key |
| collection | query | yes | the space type lexicons declared collections | a record collection NSID, or *for any |
| action | query | yes | read,create,update,delete | read_self,read,create,update,delete |
| manage | query | yes | (none) | create,update,delete |

authority, spaceType, and skey select which spaces the grant covers, matching the first three segments of a space URI. action (and collection) govern operations on the records in those spaces. manage governs operations on the spaces themselves.

authority defaults to self, the granting user's own DID, so a bare space:<spaceType> grant covers only the user's own spaces of that type. Reaching spaces under other authorities (e.g. a shared forum anchored on an app or another user) requires naming that authority, or authority=* for any.

read is all-or-nothing at the space boundary. There is no partial, per-record, or per-author whole-space read grant.

A read grant confers two things:

  • access to the read and sync methods (com.atproto.space.getRecord,listRecords,getBlob,getLatestCommit,getRepo,listRepoOps) on the holder's own PDS, sufficient to read the holder's own repo in the space
  • access to com.atproto.space.getDelegationTokenfor that space, which an application exchanges for a space credential to read any repo in the space

read_self is the narrower grant. It confers access to the same read and sync methods, but only for the holder's own repo in the space, and it does not grant getDelegationToken. An application holding only read_self can read its user's own records but cannot reach the rest of the space. read implies read_self.

A space credential grants whole-space read/sync access directly, so the read and sync methods accept either a covering OAuth scope or a space credential. Write methods accept only an OAuth credential, since a write is attributed to the authoring user.

A request is authorized by a grant when its target space matches the grant's (authority, spaceType, skey) (each component equal to the grant's value or covered by its *) and the grant permits the requested operation, per the rules below. An authority of self matches only the space whose authority is the granting user's own DID and is resolved to that DID at grant time.

Record operations are governed by action:

  • readcovers every repo in the space and ignores- collectionsince read access is all-or-nothing.
  • read_selfcovers only the holder's own repo and is constrained by- collection. A- readgrant also satisfies a- read_selfrequest.
  • create,- update, and- deleteact on a specific record, so they are additionally constrained by- collection

Omitting action grants read, create, update, and delete (read is inclusive of read_self).

Omitting collection defaults it to the collections declared by the space type's declaration. A bare space:com.atmoboards.forum grant therefore permits writing the forum's own record types, the same way a bare repo: scope permits writing the collections it names. An application may narrow this by listing a subset of collections, or widen it with collection=*. When spaceType is * there is no declaration to draw from, so the default is empty and the grant confers no write targets unless provided.

This default follows the same dynamic-update semantics as a permission set. It is resolved from the declaration as it stands when the grant is evaluated, not frozen at consent time. If the space type's declaration later adds a collection to collections, existing bare grants widen to include it once the change propagates, subject to the caching/rollout window of the authorization server that resolves the declaration. An application that does not want its authorized collection set to move with the declaration should enumerate collections explicitly rather than rely on the default.

Space management operations are governed by manage, which takes the same create/update/delete verbs applied to the space itself rather than to its records. manage ignores collection. It is omitted by default, so an ordinary record-access grant confers no administrative capability.

The protocol does not enumerate what each manage verb permits, because space management is implementation-defined (see simplespace). Each space-management implementation maps the verbs onto its own administrative surface. For example, in com.atproto.simplespace, manage=update authorizes com.atproto.simplespace.updateSpace as well as addMember and removeMember.

manage=create authorizes creating a space of the given spaceType under the given authority. Unlike every other operation, it concerns a space that does not yet exist, so scoping it to a concrete skey is unusual. It is typically granted with skey=* ("this app may create spaces of this type").

  • space:com.example.bookmarks: the user's own bookmarks space, with read access and write access to the collections its declaration lists.- authoritydefaults to- self, so this is the typical grant for personal data.
  • space:com.atmoboards.forum?authority=*: every- com.atmoboards.forumspace the user is in under any authority, with read access for the entire space and write access to the collections the forum's declaration lists (- com.atmoboards.thread,- com.atmoboards.reply). This is the typical grant for a forum client, which reads forums hosted by others.
  • space:com.atmoboards.forum?authority=*&action=read: the same spaces, read-only. No- collectionis needed because- readis not constrained by collection.
  • space:com.atmoboards.forum?authority=*&action=read_self&collection=*: read-only, and only the user's own repo in those forums. Suitable for a personal export or backup tool that should not see other members' posts. Note that- collection=*is required to read all records (not just those declared in the Lexicon).
  • space:com.atmoboards.forum?authority=*&collection=*: read access plus write access to every collection, not only the declared ones.
  • space:com.atmoboards.forum?authority=did:plc:abc123&skey=default&collection=com.atmoboards.thread&action=create&action=update: create and update- com.atmoboards.threadrecords in the forum keyed- defaultunder authority- did:plc:abc123.
  • space:com.atmoboards.forum?authority=*&action=read_self&manage=update&manage=delete: administer the user's forums (update and delete the spaces), with read access, but no record-write access.
  • space:com.atmoboards.forum?authority=*&manage=update&manage=delete: administer the user's forums (update and delete the spaces), with full read/write access to records in the space.
  • space:*?authority=did:plc:abc123: read every space under authority- did:plc:abc123, any type.

A space: scope is presented to the user on the OAuth consent screen and requires user-legible text. Each space type resolves to a space type declaration. The consent screen then displays the declaration's name (e.g. "AtmoBoards Forum") in place of the raw NSID.

If a particular authority DID is specified in a scope, it should be presented to the user as the bidirectionally linked handle associated with the DID. If no handle bidirectionally validates, then the DID itself should be shown. An authority of self refers to the user's own account and needs no such presentation.

A scope may request wildcard access on both authority and spaceType. This is a very broad grant, and as such the consent screen should present such a scope with a prominent warning.

Space permissions can also be bundled, usually with more user-friendly verbiage, into a permission set.

{ "type": "permission-set", "title": "AtmoBoards", "detail": "Read and post in your AtmoBoards forums", "permissions": [ { "type": "permission", "resource": "space", "spaceType": "com.atmoboards.forum", "authority": "*", "collection": ["com.atmoboards.thread", "com.atmoboards.reply"], "action": ["read", "create"] }, ] }
Within a permission, "type": "permission" is the entry discriminator, "resource": "space" selects the space resource, and the remaining fields carry the same parameters as the space: scope string: spaceType, authority, skey, collection, and action.

A set permission must name a concrete space type. In other words, the spaceType parameter may not be a wildcard inside a permission set. The other parameters may still be wildcards, including authority and collection. A cross-type grant (spaceType=*) is expressible only as a standalone space: scope requested directly.

When expressing space resources in a permission set, the spaceType must follow the Namespace Authority requirements associated with permission sets. However, the collection parameter may be a wildcard or list collections under a different namespace authority than the space and the permission set.

All protocol XRPC methods for permissioned data are currently defined under the com.atproto.space namespace.

These methods fall into a few loose groups:

  • Repomethods concern an account's permissioned repo within a space, and are implemented by a repo host.
  • Hostmethods concern a space as a whole, and are implemented by a space host.
  • PDSmethods are required set of baseline PDS methods that applications can build against.
  • Syncermethods concern a syncer getting real-time notifications of updates to a space or repos in a space.

This grouping describes kinds of methods, not separate services. A single service (e.g. a PDS) is usually both a repo host for its accounts and a space host for the spaces anchored on it.

| Method | Role | Type | Auth | Description |
|---|---|---|---|---|
| getSpace | host | query | space credential | Describe a space, including an open-union configcarrying host-specific configuration. |
| getSpaceCredential | host | procedure | delegation token (+ client attestation) | Exchange a delegation token for a space credential. A client attestation is also required when the space gates on client app identity. |
| listRepos | host | query | space credential | List the known repos that hold data in a space, with each repo's current revand commithash. |
| getRecord | repo | query | OAuth / space credential | Fetch a single record's value. |
| listRecords | repo | query | OAuth / space credential | List the records in a repo, inlining record values by default. Set excludeValuesfor a metadata-only listing. |
| getBlob | repo | query | OAuth / space credential | Fetch a blob by CID. |
| getLatestCommit | repo | query | OAuth / space credential | The current signed commit for a repo. |
| getRepo | repo | query | OAuth / space credential | Download a whole repo as a serialized CAR for full-state backfill. |
| listRepoOps | repo | query | OAuth / space credential | Primary sync mechanism. A repo's operation log since a given revision, inlining record values by default. Set excludeValuesfor metadata-only entries. |
| getDelegationToken | pds | query | OAuth | Mint a delegation token for a space. Served by the requesting user's PDS. |
| createRecord | pds | procedure | OAuth | Create a record in the caller's permissioned repo for a space. |
| putRecord | pds | procedure | OAuth | Create or update a record. |
| deleteRecord | pds | procedure | OAuth | Delete a record. |
| applyWrites | pds | procedure | OAuth | Apply a batch of creates, updates, and deletes to one repo atomically. |
| listSpaces | pds | query | OAuth | The spaces the caller holds a repo in. |
| registerNotify | repo/host | procedure | space credential | Register an endpoint to be notified of writes. On the space host, subscribes to the whole space. On a repo host with a repo, subscribes to that repo. |
| notifyWrite | syncer/host | procedure | service auth | Notify that a repo advanced. Sent by a repo host to the space host, and forwarded by the space host to registered syncers. |
| notifySpaceDeleted | syncer/repo | procedure | service auth | Notify that a space was deleted. Sent by the authority to members and registered syncers. |

The protocol does not specify how spaces are created or how an authority decides who may read them. Those are the concern of each space-management implementation, which sits above the protocol and is identified by its own lexicon namespace.

com.atproto.simplespace is the space-management implementation that every PDS MUST support. It gives applications a baseline that is available on every account's PDS to build against. simplespace spaces are anchored on a user's own DID and governed by an explicit member list (or the public and managing-app policies described below).

simplespace is neither the only permitted implementation nor a privileged one. It is simply the one that PDSs are required to support. Other space types may define their own management implementations and are full protocol participants, but they are hosted on bespoke space services rather than on the PDS.

All simplespace methods are called with an OAuth credential with the relevant manage scope.

| Method | Type | Description |
|---|---|---|
| createSpace | procedure | Create a space (caller becomes the authority) |
| updateSpace | procedure | Update config (more details below) |
| deleteSpace | procedure | Delete the space (see Space deletion). |
| addMember | procedure | Add a member (by DID) to view the space. |
| removeMember | procedure | Remove a member (by DID). |
| listMembers | query | List the current members of a space. |

simplespace spaces can be further configured along a few dimensions. This configuration is updated through updateSpace and is surfaced through com.atproto.space.getSpace.

| Field | Values | Description |
|---|---|---|
| policy | public|member-list|managing-app | How the authority decides whether to authorize a user. |
| appAccess | open union ( #open|#allowList) | How the authority decides whether to authorize an app. |
| managingApp | service identifier (DID + fragment) | Used to route application requests, and as the access check target in managing-appmode. |

A user must be authorized by the policy and their app by appAccess for a credential to be minted. A syncing app needs a valid delegation token regardless.

Policy decides per-user authorization:

  • member-list(default): authorize requesters present on the member list.
  • public: authorize any requester.
  • managing-app: at mint time, ask- managingAppwhether to authorize the request, via- checkUserAccessbelow. Enables dynamic policies (e.g. follower-gating) without an app maintaining a list.

App access decides per-app authorization. It is an open union with two current variants:

  • #open(default): any application may access the space. No client attestation is required, so public clients work.
  • #allowList: only the apps named in- allowedmay access the space. The authority evaluates the list against the- attested- client_id(the- issof the verified client attestation), so it is enforceable rather than advisory.

Spaces may list a managingApp. Any account with access to the space can read the selected managing app in the space config through com.atproto.space.getSpace. This endpoint may be used to route certain application-level requests that cannot be handled by a generic PDS implementation, such as join requests. Calls to managing apps are generally authenticated using service auth tokens.

When a space's policy is managing-app, the space authority defers to the space's managingApp at mint time by calling com.atproto.simplespace.checkUserAccess.

Unlike the other simplespace methods, checkUserAccess is served by the managingApp, not the PDS. The authority calls it with itself as iss and the managingApp's service identifier as aud, so the app can verify the call genuinely originates from the space's authority. It passes the space, the requesting user, and the requesting client (the attested client_id, if any), and the managing app returns whether to authorize.

The app evaluates the request against whatever application-layer state it maintains (e.g. follower graphs, paid-subscription status, join approvals) and returns its decision. The authority mints the credential only if the app authorizes and applies appAccess as usual.

This section is non-normative. It discusses how permissioned data interacts with concerns that span the whole protocol. The short answer to most of them is that permissioned data behaves much like public broadcast, because it deliberately keeps the same shape: DID-based authority, per-user repositories, lexicon-typed records, and applications that crawl repos to build views.

Moderation in public broadcast atproto is handled at various levels, including labeling and infrastructure takedowns. Every service in the network is able to, and must, moderate the data it hosts and serves according to its legal requirements, terms of service, and community guidelines. In addition, moderation services may publish public labels that applications and infrastructure providers can then act on.

Permissioned data keeps this model, with the obvious difference that the data is not open, and therefore a moderation service cannot observe a space it has not been admitted to. A moderation service functions as just another reader. To label content in a space, a moderation service must hold a space credential like any other syncer, which means the space authority has admitted it under the same access control rules.

A moderation service should not publish public labels for records in permissioned spaces, as this leaks metadata about otherwise-private data. The public com.atproto.label.subscribeLabels endpoint is therefore a poor fit here. Instead, labelers may publish labels as records in a permissioned repo within the relevant space, keeping the labels inside the same access boundary as the content they describe.

At the infrastructure level, familiar tools and processes apply. Each participant retains authority over their own repo and can delete their own records. A repo host can take down accounts or refuse to serve repos that it hosts. An application can filter records from the views that it serves.

A space authority has an additional lever with no public analogue. Because reading requires a credential it issues, it can decline to issue one to a user and thereby cut off read access, or stop issuing credentials for the space entirely (see space deletion). Some spaces may also include records with application-level semantics for restricting writes from moderated users.

The scaling story is expected to be similar to the public broadcast protocol. Data is partitioned per user across many hosts, no single node (at the hosting layer) holds an entire space, and applications may choose how much and which data they wish to index.

The one major difference is the lack of relays. Applications sync permissioned repos directly from PDSes rather than relying on an intermediary service, which places additional load on PDSes. A few things make this more approachable.

First, the sync protocol itself is significantly lighter-weight than public sync, as it does not carry the overhead of maintaining and transmitting the structural nodes of the MST.

Second, sync load scales with the number of applications syncing a space, not the number of end users. An application serving many users pulls each repo once and fans it out to them from its own copy, which keeps the number of distinct syncers per repo relatively low.

Finally, and relatedly, the sync APIs are not open to the public, so resource abuse is much easier to mitigate. Each sync method requires a space credential, which is generally issued only to a closed set of syncers, and can be correlated across requests to enforce rate limits and other controls.

An account's participation in permissioned data is tied to the same DID and signing key as its public atproto identity. The lifecycle events that already exist, migration, key rotation, deactivation, and deletion, therefore all function the same way in the context of permissioned data.

Migration. Moving a permissioned repo between hosts functions the same as migrating a public repository. The main difference is that a user has many permissioned repos rather than one, so account migration flows will need to enumerate and track all of an account's permissioned repos and the blobs associated with them.

Deactivation & deletion. Deactivation and deletion function exactly as they do for public broadcast. If an account is deleted, downstream services are expected to delete all public and permissioned data associated with the account. If an account is deactivated, downstream services are expected to stop serving all public and permissioned data associated with it.

Identity & account events. Applications currently learn about changes to an account's status or identity (such as its signing key and handle) via events on the firehose (com.atproto.sync.subscribeRepos). These same account updates apply to permissioned repos in exactly the same manner. This means an application that syncs only permissioned repos, and no public repositories, still needs to subscribe to a firehose to receive #account and #identity events. Future work may include an additional subscription endpoint that broadcasts only those two event types without the full stream of public repository commits.
