A minimal, high-performance 2D (g)raphics (p)ainter for
SDL3.
This is a port of sokol_gp to SDL3, with one main difference:
sokol_gp relies on sokol, which manages resources internally. SDL_gpu is lower-level and does not; So SDL_gp provides a simple resource management system very similar to sokol's.
Primitive:
Rectangle:
Sprite:
Blendmode:
If you want to jump in the right way, check out the samples folder.
here is a simple example to draw a red rectangle:
// Acquire a command buffer for the current frame
SDL_GPUCommandBuffer *cmd_buffer = SDL_AcquireGPUCommandBuffer(device);
// Begin a new frame
SDL_GPBegin(WINDOW_WIDTH, WINDOW_HEIGHT);
{
// Clear the screen to black.
SDL_GPSetColor((SDL_Color){ 0, 0, 0, 255 });
SDL_GPClear();
// Draw a red filled rectangle.
SDL_GPSetColor((SDL_Color){ 255, 0, 0, 255 });
{
SDL_GPDrawRectFilled((SDL_GPRect){ 10, 10, 100, 100 });
}
// The caller can render to a swapchain or to a texture. Here we render to
// the swapchain.
SDL_GPUTexture *swapchain_texture = NULL;
SDL_WaitAndAcquireGPUSwapchainTexture(
cmd_buffer, window, &swapchain_texture, NULL, NULL);
SDL_GPFlush(cmd_buffer, swapchain_texture);
}
SDL_GPEnd();
SDL_SubmitGPUCommandBuffer(cmd_buffer);
SDL_Delay(DELTA_TIME_MS);
Error API:
// Get the last error that occurred in SDL_gp. Returns SDL_GP_ERROR_NONE if no
// error has occurred.
SDL_GP_Error SDL_GPGetLastError(void);
// Get a human-readable string describing an SDL_GP_Error value. Returns
// "Unknown error" if the error value is not recognized.
const char *SDL_GPGetErrorMessage(SDL_GP_Error error);
Image API:
// Create an image from an SDL_Surface. Returns an invalid image if creation
// failed, use SDL_GPGetLastError() to get more information about the error.
SDL_GPImage SDL_GPCreateImage(SDL_Surface *surface);
// Destroy an image and free its resources.
void SDL_GPDestroyImage(SDL_GPImage image);
// Get the GPU texture associated with an image. Returns NULL if the image is
// invalid.
SDL_GPUTexture *SDL_GPGetImageGPUTexture(SDL_GPImage image);
// Get the width of an image in pixels. Returns 0 if the image is invalid.
int SDL_GPGetImageWidth(SDL_GPImage image);
// Get the height of an image in pixels. Returns 0 if the image is invalid.
int SDL_GPGetImageHeight(SDL_GPImage image);
Shader API:
// Create a shader from vertex and fragment shader descriptions. Returns an
// invalid shader if creation failed, Use SDL_GPGetLastError() to get more
// information about the error.
SDL_GPShader SDL_GPCreateShader(SDL_GPShaderDesc *desc);
// Get the SDL shader associated with a SDL_gp shader. Returns NULL if the
// shader is invalid.
SDL_GPUShader *SDL_GPGetGPUShader(SDL_GPShader shader);
// Destroy a shader and free its resources.
void SDL_GPDestroyShader(SDL_GPShader shader);
Pipeline API:
// Create a graphics pipeline, Returns an invalid pipeline if creation failed,
// Use SDL_GPGetLastError() to get more information about the error.
SDL_GPPipeline
SDL_GPCreatePipeline(SDL_GPShader shader_vert,
SDL_GPShader shader_frag,
SDL_GPPrimitiveType primitive_type,
SDL_GPBlendMode blend_mode);
// Destroy a graphics pipeline and free its resources.
void SDL_GPDestroyPipeline(SDL_GPPipeline pipeline);
// Get the GPU graphics pipeline associated with a SDL_gp pipeline. Returns
// NULL if the pipeline is invalid.
SDL_GPUGraphicsPipeline *SDL_GPGetGPUPipeline(SDL_GPPipeline pipeline);
Painter API:
// Setup SDL_GP context. Returns false if setup failed, use
// SDL_GPGetLastError() to get more information about the error.
bool SDL_GPSetup(SDL_GPDesc *desc);
// Shutdown SDL_GP context.
void SDL_GPShutdown(void);
// Begin recoarding draw calls for the current frame. This should be called
// after setting up SDL_gp and acquiring a swapchain texture and command
// buffer for the current frame.
// If return false then an error occurred and the frame should be skipped,
// use SDL_GPGetLastError() to get more information about the error.
bool SDL_GPBegin(int width, int height);
// Flush the recorded draw calls to the GPU. Returns false if an error
// occurred, use SDL_GPGetLastError() to get more information about the error.
bool SDL_GPFlush(SDL_GPUCommandBuffer *cmd_buffer, SDL_GPUTexture *texture);
// End recording draw calls for the current frame.
void SDL_GPEnd(void);
// Set the coordinate space boundaries in the current viewport.
void SDL_GPSetProjection(float left, float right, float bottom, float top);
// Reset the projection to the default coordinate space, which is the
// coordinate of the current viewport.
void SDL_GPResetProjection(void);
// Save the current transform matrix on the transform stack. To be pop later
// with SDL_GPPopTransform.
void SDL_GPPushTransform(void);
// Restore the transform matrix from the top of the transform stack.
void SDL_GPPopTransform(void);
// Set the current transform matrix to identity (no transformation).
void SDL_GPResetTransform(void);
// Translates the 2D coordinates space.
void SDL_GPTranslate(float x, float y);
// Rotates the 2D coordinate space around the origin.
void SDL_GPRotate(float angle);
// Rotates the 2D coordinate space around a point.
void SDL_GPRotateAt(float angle, float ax, float ay);
// Scales the 2D coordinate space around the origin.
void SDL_GPScale(float sx, float sy);
// Scales the 2D coordinate space around a point.
void SDL_GPScaleAt(float sx, float sy, float ax, float ay);
// Set the current graphics pipeline.
void SDL_GPSetPipeline(SDL_GPPipeline pipeline);
// Reset the graphics pipeline to the default pipeline builtin pipeline.
void SDL_GPResetPipeline(void);
// Set uniform data for the current pipeline.
void SDL_GPSetUniform(const void *vs_data, size_t vs_size, const void *fs_data, size_t fs_size);
// Reset uniform data to the default state (current state color).
void SDL_GPResetUniform(void);
// Set the current blend mode.
void SDL_GPSetBlendMode(SDL_GPBlendMode blend_mode);
// Reset the current blend mode to the default blend mode (no blending).
void SDL_GPResetBlendMode(void);
// Sets current color.
void SDL_GPSetColor(SDL_Color color);
// Gets current color.
SDL_Color SDL_GPGetColor(void);
// Reset current color to the default color (white).
void SDL_GPResetColor(void);
// Sets current bound image in a texture channel.
void SDL_GPSetImage(int channel, SDL_GPImage image);
// Remove current bound image from a texture channel (no texture).
void SDL_GPUnsetImage(int channel);
// Reset current bound image in a texture channel to the default (white
// texture).
void SDL_GPResetImage(int channel);
// Set current bound sampler in a texture channel.
void SDL_GPSetSampler(int channel, SDL_GPUSampler *sampler);
// Remove current bound sampler from a texture channel (no sampler).
void SDL_GPUnsetSampler(int channel);
// Reset current bound sampler in a texture channel to default (nearest
// sampler).
void SDL_GPResetSampler(int channel);
// Set the screen are to draw to.
void SDL_GPViewport(int x, int y, int w, int h);
// Reset the viewport to default (0, 0, width, height).
void SDL_GPResetViewport(void);
// Set the clipping rectangle in the viewport.
void SDL_GPScissor(int x, int y, int w, int h);
// Reset the clipping rectangle to default (viewport bounds).
void SDL_GPResetScissor(void);
// Reset all state to default.
void SDL_GPResetState(void);
// Clear the current viewport with the current color.
void SDL_GPClear(void);
// Draw any primitive.
void SDL_GPDraw(SDL_GPPrimitiveType primitive_type, const SDL_GPVertex *vertices, Uint32 vertices_count);
// Draw points in batch.
void SDL_GPDrawPoints(const SDL_GPPoint *points, Uint32 count);
// Draw a single point.
void SDL_GPDrawPoint(SDL_GPPoint point);
// Draw lines in batch.
void SDL_GPDrawLines(const SDL_GPLine *lines, Uint32 count);
// Draw a single line.
void SDL_GPDrawLine(SDL_GPLine line);
// Draw a stip of lines.
void SDL_GPDrawLinesStrip(const SDL_GPVec2 *points, Uint32 count);
// Draw triangles in batch.
void
SDL_GPDrawFilledTriangles(const SDL_GPTriangle *triangles, Uint32 count);
// Draw a single triangle.
void SDL_GPDrawFilledTriangle(SDL_GPTriangle triangle);
// Draw a strip of triangles.
void SDL_GPDrawFilledTrianglesStrip(const SDL_GPVec2 *points, Uint32 count);
// Draw rectangles in batch.
void SDL_GPDrawFilledRects(const SDL_GPRect *rects, Uint32 count);
// Draw a single rectangle.
void SDL_GPDrawFilledRect(SDL_GPRect rect);
// Draw textured rectangles in batch.
void SDL_GPDrawTexturedRects(int channel, const SDL_GPTexturedRect *rects, Uint32 count);
// Draw a single textured rectangle.
void SDL_GPDrawTexturedRect(int channel, SDL_GPTexturedRect rect);
Hi everyone, I'm nsix, an indie game developer and open source contributor trying to make a living from my work.
If you enjoy what I create and want to support me, consider becoming a sponsor on GitHub Sponsors. Every bit of support means a lot and is greatly appreciated!
You can also check out my blog at www.nsix.blog for more updates and insights into my work.
- Edubart - Creator of the original
sokol_gpthat encouraged me to createSDL_gp. - The SDL team - For developing and maintaining
SDL3.
This project is licensed under the MIT License - see the LICENSE file for details.
